Safety Hydraulic Shearing Machine Hydraulic Iron Worker Punch And Shear Machine

Place of Origin CHINA
ชื่อแบรนด์ FRIENDSHIP MACHINERY
ได้รับการรับรอง CE, ISO
Model Number Q35Y
Minimum Order Quantity 1
ราคา USD12000
รายละเอียดสินค้า
Name Double-cylinder hydraulic punch & shear machine Cutting angle 7 / 8 degree
Ram stroke 80 Number of strokes 8 / 6
แสงสูง

hydraulic guillotine shearing machine

,

hydraulic press brake machine

ฝากข้อความ
รายละเอียดสินค้า

1. Introduction



● Double-cylinder hydraulic punch & shear machine

● Five independent stations for punching, shearing, notching, cutting and bending

● Large punching table with multi-purpose bolster

● Rear notching station, Low power inching and adjustable stroke at punching station

● Centralised pressure lubrication system

● Electric panel with overload protection elements and integrated controls

● Safety movable foot pedal





2. Accessories List



● A set of hole punching die

● A set of angle steel blade

● A set of square and round bar blade

● A set of shearing plate blade

● A set of notching blade





3. Tecnical parameter



Specification Unit Q35Y-16 Q35Y-20 Q35Y-25 Q35Y-30
Pressure Ton 55 75 110 140
Max.cutting tickness Mm16 16 20 25 30
Plate strength n/mm2 <450 <450 <45 <45
Cutting angle degree 7 8 8 8
Shearing size of one stroke mm 16*250, 8*400 20*330, 10*480 25*300, 16*600 30*355, 20*600
Ram stroke mm 80 80 80 80
Number of strokes cpm 8 8 6 8
Throat thickness mm 300 355 400 600
Pumching thickness mm 16 20 25 26
Max.Puching diameter mm 25 30 35 38
Power of main motor Km 4 5.5 7.5 11
Over al dimensions(L*W*H) Mm 1640*730*1770 1860*800*1900 2355*960*2090 2680*1040*2330
Weight of machine Kg 1600 2000 4800 6800



Safety Hydraulic Shearing Machine Hydraulic Iron Worker Punch And Shear Machine 0
